Allen-Bradley - PowerFlex Air Cooled 753 AC Dr - 20F1AGC260JN0NNNNN

PowerFlex 753 AC Drive, with Embedded I/O, Air Cooled, AC Input with Precharge, no DC Terminals, Type 12 / IP54, 260 Amps, 132kW ND, 110kW HD, 400 VAC, 3 PH, Frame 7, Filtered, CM Jumper Installed, None, Blank (No HIM)

• •Power ratings: ◦380…480V: 0.75…250 kW / 1.0…350 Hp / 2.1…456 A

• ◦600V: 1.0…300 Hp / 1.7…289 A

• ◦690V: 7.5…250 kW / 12…263 A

• •IP00/IP20 NEMA/UL Type Open, flange mount, IP54 NEMA/UL Type 12

• •Dual-port EtherNet/IP™ Option Module helps you leverage EtherNet/IP networks, minimize the number of managed switches, and reduce cabling needs when using Device Level Ring (DLR) networks

• •V/Hz control, vector control with FORCE™ technology and sensorless vector control

• •Predictive diagnostics to extend the life of cooling fans and relay outputs

• •Slot-based architecture provides three option slots for feedback, safety, communications, additional I/O, or an auxiliary power supply

• •Configuration and programming via integral LCD Human Interface Module (HIM), DriveTools SP software, Connected Components Workbench software, or Studio 5000 Logix Designer® software

• Available Embedded Safety Options

• •Safe Torque-Off option is certified at PLe/SIL3 CAT 3

• •Safe Speed Monitor combines the Safe Torque-Off capability and an embedded safety relay with the Rockwell Automation® Safe-Speed Control core technology in one hardware option embedded in the drive. Certified PLe/SIL3 CAT 4
